This single station fixture is used to EDM
.015" diameter holes in a titanium part
using a conventional electrical discharge
machine.
The fixture orients and holds the part,
locates and guides the wire electrodes to
twenty-five different locations on ten
different angles that vary from 8 degrees
to 30 degrees off vertical.
